HONOR sheet to sheet Automatic nc paper cutter
This is industrial hydraulic die cutting machine from Honor Machinery.
It is a heavy-duty guillotine style cutter intended for trimming large stacks of paper. We select the best materials to make the machine. The machine frame is cast using resin sand molding. And the internal structure is cast.
This goal of design is to reduce friction among moving parts and extend the equipment's service life. The exterior is finished with imported atom-gray spray paint. The durable surface is scratch-resistant, heat-resistant, and less prone to cracking or blistering.
Specifications
Paper sheet cutting machine, computer control, easy to operate, can adjust a variety of sizes.Like A4/A3 etc.
1.Chrome-plated slot-less working table installed with double imported liner guide and air cushion
2.Mechanical assistance device for knife replacement
3.Overload protection safety device
4.Infrared photoelectric protection device
5.Fluorescent lamp and cutting line indicator
6.Ejective device
7.Use imported components in hydraulic system like atos and hassan
8.Use imported electronic units like SIMENS, TOSHIBA, ORMON, LG
9.PLC control
10.Use imported mechanic components like NSk BEARING
11.Imported motor and motor made in china is optional
Single hydraulic and double hydraulic is optional
|
TECHNICAL SPECIFICATION |
|||||
|
Model |
Units |
32 |
36 |
45 |
52 |
|
Cutting width |
mm |
810 |
920 |
1150 |
1320 |
|
Clamp opening |
mm |
100 |
110 |
165 |
165 |
|
Feed depth |
mm |
810 |
920 |
1150 |
1320 |
|
Power |
H.P. |
5 |
5 |
7 |
9.5 |
|
Weight, net |
Kg |
2500 |
2800 |
3800 |
4300 |
|
Width, |
|
|
|
|
|
|
without side tables |
mm |
1870 |
1970 |
2330 |
2540 |
|
with side tables |
mm |
1910 |
2130 |
2650 |
2880 |
|
Length |
mm |
1950 |
2100 |
2540 |
2820 |
|
Height |
mm |
1400 |
1530 |
1650 |
1650 |
|
Front table length |
mm |
680 |
680 |
750 |
750 |
|
Table height |
mm |
900 |
900 |
900 |
900 |
|
Clamping pressure, min. |
daN |
200 |
200 |
200 |
200 |
|
max. |
daN |
3500 |
3500 |
4500 |
5500 |
|
Smallest cut |
|
|
|
|
|
|
without false clamp plate, min. |
mm |
25 |
25 |
25 |
25 |
|
with false clamp plate, min. |
mm |
65 |
70 |
80 |
80 |
Strengths
(1)Around 95% of the parts are processed intensively by our factory's workers who have many years experience in this field.
(2)We have nearly 20 years experience in paper cutting machine, our machine are in great demand at home and abroad. These years, our machines and services have been widely well-received.
(3)We specialize in after-sales service in our factory. If you have any questions, please call us without hesitation. We will do our best to solve it as soon as possible.
(4)We have strictly follow CE and ISO9001 standard certification.
(5)Before the actual installation,we will communicate with the customer to understand the installation needs and requirements. Installation and commissioning finished, our engineer will also help train your workers how to operate.
(6)Installation and commissioning of machine. Respond to consumer questions, answer consumer inquiries, and deal with consumer comments within 7/24. Fast and flexible response.
