High speed automatic computerized paper cross cutting machine
Features:
1. Paper cutting unit
• Adopt translate cutting-knife
• Adopt imported ABB Linear guide
• High precision special steel knife
• Cutting precision +0.3mm
2. Paper feeding unit
• Double arm oil pressure no-axle paper reel rack
• Tension control system
• PLC control paper position
3. Paper operation unit
• The face of operation controlled by computer
• The operation is simple and convenient
4. Electric control unit
• PLC control system
• AC servo motor
• High precision encoder
• High precision cutting
• Long endurance
• Adopt panasonic transducer
5. Paper delivery unit
• The number of overlapping sheet can be adjusted by the overlapping unit
• Single sheet outlet can be adjusted by the overlapping unit
Specifications:
Model | HONOR-1450 | HONOR-1700 | HONOR-1900 | |
Paper weight | gsm | 60-550 | ||
Max. cutting width | mm | 1450 | 1700 | 1900 |
Cutting accuracy | mm | ±0.3 | ||
Max. cutting speed | sheets/min | 160 | ||
m/min | 90 | |||
Cutting length | mm | 450-1450 | ||
Max scroll diameter | mm | 1800 | ||
Paper pilling hegith | mm | 1200 | ||
Weight | kg | 6000 | 7000 | 8000 |
Machine color, size, can be customized according to your requirements.
We have more than 15 years experience engineers in paper machinery,We can provide after-sale service and spare parts. You can contact our 24 hours:
