Sinotop Industry Group
The factory is located in the south and north of China. We have advanced paper cutting machine, roll to sheet cutting paper machine, auto paper sheeter, slitting and rewinding machine, A4 copy paper cutting machine and A4 copy paper packing machine. Based on the central plains, looking around the world.
Products Description
This machine is used for slitting and rewinding various large rolling materials such as paper, (kraft paper, cellophane paper bill paper), double-face adhesive tape, PVC, plastic material, etc.
1. This machine use PLC controller, automatic taper tension, central surface reeling.
2.Frequency converter three motor vector control, keeping speed up and stable operation. It has the functions of automatic metering,automatic alarm,etc.
3.With A, B inflatable shaft structures for rewinding; Finished products are automatic loading and unloading. It adopts photoelectric automatic error correction adjustment system for unwinding, anomalistic materials will be easy slit.
4.Equipped with automatic waste paper inhaling blowing device. Automatic material loading by hydraulic system for unwinding.
Parameter
|
Model |
HONOR-1300 |
HONOR-1600 |
HONOR-1800 |
|
Max.Width of unwinding |
1300mm |
1600mm |
1800mm |
|
Max.Diameter of unwinding |
φ1600mm |
φ1600mm |
φ1600mm |
|
Min.Width of slitting |
50mm(up to materials) |
50mm(up to materials) |
50mm(up to materials) |
|
Max.Diameter of rewinding |
φ1500mm |
φ1500mm |
φ1500mm |
|
Speed |
10-350m/min |
10-350m/min |
10-350m/min |
|
Total power |
48kw |
50kw |
63kw |
|
Power supply |
380V/50hz |
380V/50hz |
380V/50hz |
|
Weight |
12000kg |
14000kg |
16000kg |
|
Overall dimension (LxWxH) |
7500×3500x2400(mm) |
7500×3700x2400(mm) |
7500×3800x2400(mm) |
What we use in production
FAQ
Packaging and Shipment
Packaging: Standard export wooden pallet, wooden box, anti-collision, moisture-proof treatment.
Delivery Time: 7-30 working days after deposit(shorter for standard configurations).
Shipping Port: Qingdao Port, China (other ports available on request).
Installation: Free online installation guidance; on-site commissioning service available (extra cost).
Customer Service
Warranty: 1 year
Spare Parts: Free easy-wear parts package; long-term supply at factory prices.
Technical Support: 24/7 online service, response within 24 hours.
Training: Free online operator training.
Contact us
Get the latest factory price and detailed quotation! We support full customization to match your production capacity, workshop layout, and budget.Your inquiry will be replied within 24 hours!
E-mail:sales1@honor-machinery.com
Mobile/Wechat/whatsapp:0086-15737839119
Common Problem
Why choose us to cooperate?
Factory prices, flexible payment terms and professional quality inspection team which has the guarantee for machines, in time after sales service, and more than 20 years experience for exporting. Reputation and quality is what we are considering all the time.
Guarantee?
The product has a 12-month warranty from the date of installation. And we provide lifetime technology support online.
Do you have Installation and Training service if we bought the machines from your company?
Our professional engineers will go to the site to install and commission the machinery and equipment, and provide hands‑on training.
Have you sold any machines to our country?
We have to say that there are 120 countries' customers who have our machines till 2026. Pls check with the sales manager to get more information if you need the machines' feedback.
cooperative partner
Get the latest factory price and detailed quotation! We support full customization to match your production capacity, workshop layout, and budget.Your inquiry will be replied within 24 hours!
E-mail:sales1@honor-machinery.com
Mobile/Wechat/whatsapp:0086-15737839119
Hot Tags: honor-2000 fully automatic paper slitting & rewinding unit, China, manufacturers, suppliers, factory, for sale
