Parameters and Indicators:
1, material type: white board paper, carbon free paper, film paper, double adhesive paper and other materials;
2. Material thickness: 60-450g (paper)
3. Maximum diameter of raw material: 1500mm
4. Material tube core: 3-6# paper tube;
5. Maximum width of raw material: 1300mm;
6. Minimum width of raw material: 800mm
7. Roll width: 1350mm;
8. Cutting width: 50-1300mm;
9. Winding tube core: 3 inches
10. Maximum diameter of winding: 1500mm;
11. Total deviation correction stroke: 150mm;
12 correction accuracy: ±0.15mm
13. Maximum speed: 350 m/min;
14. Cutting speed: 10-- 350 m/min;
15. Total power:
16. Total weight: about 13 tons;
17. Dimensions: 7500 long, 3700 wide, 2300mm high;
18. Slitting tool: according to user requirements, standard configuration of 20 sets
19. Upper knife: φ 160*100*50mm.
20. Lower round knife: φ 150*120*20mm.
21. Material receiving shaft: 2 3# air expansion shaft
22. The whole equipment is equipped with 15 φ 120 aluminum rollers, 1 rubber roller and 1 active steel roller.
